M8 - The Lagoon Nebula

Click to Zoom

M8 and M20, the Lagoon and Trifid Nebulae in Sagittarius, in (Ha+R)GB.

Location: Texas Star Party 2004 near Fort Davis, Texas (Ha Luminance); FWAS dark sky site near Springtown, Texas (RGB)

Seeing: 5/10 (Luminance), 5/10 (RGB)

Transparency: 8/10 (Luminance), 5/10 (RGB)

Date and Time: May 21, 2003 (Luminance), September 11, 2004 (RGB)

Equipment: Tak FSQ-106 @ f/5 with Tak NJP mount

Camera: SBIG STL-6303E NABG with integrated filter wheel

Filter: Custom Scientific 5 nm H-alpha filter

Exposure Info: (Ha+R)GB. Ha luminance - 35 x 1 minute exposures (best of 55). RGB - 40:35:30 minutes (5 minute sub-exposures unbinned).

Processing Information: Darks, flats, deblooming, alignment, stacking, RGB combine, and digital development in MaxIm DL 4. Curves, Levels, selective Unsharp Mask, and Color balance in Photoshop CS.

Exposure Notes: I took the short Ha luminance shown below and blended it into the Red channel 50%. I chose this method because the length of the luminance wasn't long enough to stand on its own, which would have brought too much noise into the image.

Special thanks to the Three Rivers Foundation (3RF) for the use of some of the equipment used to create this image.

About this Object

Messier 8 is a diffuse nebula (NGC 6523) and star cluster (NGC 6530). It is one of the few nebulae easily visible to the naked eye, shining bright at 4.6 magnitude and spreading out more than 1.5 degrees across the sky (the moon is 0.5 degrees). The "Lagoon" gets its name from the dark nebular band that separates the nebula into two lobes. Messier 20, known as the Trifid Nebula due to its three part lobe shape, is also comprised of both nebulosity and a cluster. In fact, Messier himself described only the cluster portion of this object.

Previous exposure

An earlier attempt at the Lagoon Nebula, Ha luminance only, May 2003

Location: Texas Star Party 2004 near Fort Davis, Texas
Seeing: 5/10
Transparency: 8/10
Date and Time: May 21, 2003
Equipment: Tak FSQ-106 @ f/5 with Tak NJP mount
Camera: SBIG STL-6303E NABG with integrated filter wheel
Exposure Info: Grayscale, h-alpha luminance. Length: 35 x 1 minute exposures (best of 55) - unguided
Filter: Custom Scientific 5 nm H-alpha filter
Processing Information: Deblooming, alignment, stacking and digital development in MaxIm DL 4. Curves and Levels in Photoshop CS.

Exposure Notes: When you have guiding issues, this is the way you do it! After fighting with a finicky autoguider, I decided to rip off about an hour's worth of one minute, unguided exposures. I ended up with 35 quality images to stack. The results are quite nice. When astronomy gives you lemons….

Previous exposure

An even earlier film exposure of the Lagoon and Trifid Nebulae, May 2003

Simply gorgeous! The dark lanes in both nebulae can easily be seen here. Open cluster M21 appears to the upper left of the Trifid. These objects light up the summer Milky Way sky, easily naked eye objects in dark skies. The views are stunning in binoculars or small telescope. But the best view is in a big apertured scope. Simply jaw dropping!

Location: Texas Star Party 2003 near Fort Davis, Texas
Seeing: 7/10
Transparency: 9/10
Date and Time: May 3, 2003 @ 3:00 AM and 3:10 AM CST
Equipment: 420mm @ f4 (300mm Nikkor ED lens with TC14B teleconverter) guided with Meade 208xt
Length: A 6 minute and an 8 minute exposure stacked and averaged
Film: Kodak E200 slide film with one stop push to ISO 320
Processing Information: Image is slightly cropped with a levels adjustment and contrast increase. Slight unsharp mask applied.

🤖 AI-drafted · unverified

What it is: M8, the Lagoon Nebula, is a large emission nebula and stellar nursery — bright enough to be glimpsed with the naked eye under dark skies.
Constellation: Sagittarius
Distance: ~4,100 light-years
Apparent magnitude: ~6.0
Angular size: ~90 × 40 arcminutes
Coordinates: RA 18h 03m 37s, Dec -24° 23′

This summary was generated by an AI assistant from general astronomical references, not from Jay's own notes on this specific image. Treat every detail above as a starting point for research, not settled fact.
