Pleiades (M45) Mosaic - Four Frames of the Seven Sisters
A four-frame mosaic covering Merope, Electra, Alcyone, and Maia, combining fresh luminance data with color data taken from a previous LRGB image of the cluster.
Observatory: The Conley Observatory - Data acquired via remote from Grapevine, TX
Location: Comanche Spring Astronomy Campus (CSAC), Three Rivers Foundation, Crowell, Texas
Date: November 2017 (luminance) & November 2009 (color - see image below)
Scope/Mount: 12.5" RCOS Ritchey-Chretien and Paramount ME mount (luminance); Tak TOA-150 (with Flattener) and Paramount ME mount (color)
Camera: FLI Proline PL-16803 astro CCD camera (luminance); SBIG STL-11000M astro CCD camera (color)
Exposure Info: Luminance data comprises a 4-frame mosaic of 100 minutes (Merope frame), 100 minutes (Electra frame), 160 minutes (Alcyone frame), and 90 minutes (Maia); 10-minute subexposures, all unbinned. Color data taken from previous LRGB image (shown below), 160:60:50:30 minutes; 10 minute subexposures all unbinned.
Total Exposure Time: 12.5 hours
Processing Information (Luminance): Acquisition in TheSkyX Pro of 4 mosaic frames. Calibration, registration, and integration of all frames in PixInsight 1.8.5. Mosaic "stitching" in PixInsight using Gradient Merge Mosaic process. Multiscale Linear Processing used for noise removal in PixInsight. Histogram Transformation in PixInsight.
Processing Information (Color): Acquisition in CCDSoft V5. Calibration, Registration, and DDP in CCDStack. LRGB combine, cropping, color balance, levels/curves, sharpening, and noise removal (despeckle and gaussian blur) in Photoshop CS2. Color Blotch Reduction, Deep Space Noise Removal, and Local Contrast Enhancement in Photoshop via ProDigital Actions for Photoshop.
Processing Information (LRGB): Images aligned in PixInsight, saved as 16-bit TIFF files, and brought into Adobe Photoshop CC for further processing. "Make Stars Smaller" action (ProDigital) to help with star matching between Lum and color. AstroFlat Pro (ProDigital) used to reduce glare in luminance, revealing more dust. High-pass filtering used for sharpening and various noise reduction techniques used for cleaning up the background. Vibrance/Saturation, cropped, and rotated in Photoshop for more visual impact.
- What it is
- M45, the Pleiades or "Seven Sisters," is a bright, young open star cluster wrapped in wisps of blue reflection nebulosity.
- Constellation
- Taurus
- Distance
- ~444 light-years
- Apparent magnitude
- 1.6 (cluster); 2.9โ5.6 (nine brightest stars)
- Angular size
- ~110 arcminutes
- Coordinates
- RA 03h 47m, Dec +24ยฐ 07โฒ
This summary was generated by an AI assistant from general astronomical references, not from Jay's own notes on this specific image. Treat every detail above as a starting point for research, not settled fact.
